Product Introduction
The BJPX-MT series drug stability test chamber is manufactured in accordance with the relevant requirements of GBT10586-2006 "Technical Conditions for Damp Heat Test Chambers". To meet the "Guiding Principles for Stability Testing of Chemical Raw Materials and Preparations" and create a long-term stable temperature and humidity environment for drug expiration evaluation, suitable for pharmaceutical companies to conduct stability testing and experimentation of drugs and new drugs. In addition to meeting the requirements of accelerated testing, long-term testing, and high humidity testing as stipulated in the "Guidelines for Stability Testing of Chemical Raw Materials and Preparations", users can also set their own test parameters according to the stability testing requirements of their unit's drugs.
Technical indicators
1. Intelligent centralized control and monitoring
① A computer can monitor multiple devices of the same series simultaneously through wired or wireless connections, enabling remote monitoring from different locations;
② ★Real time communication between various terminals with communication functions such as mobile phones and PCs and the content of the test box;
③ The monitoring content includes: set value, measured value, date, running time, running curve, alarm record;
④ Micro needle printer paper records, with adjustable printing frequency;
⑤ ★The controller has built-in data recording, which can record more than 1 million pieces of data according to the recording frequency set by the operator, avoiding data loss during power failure. The data can be exported through a USB flash drive;
⑥ ★It has three-level password permission management function, can be operated at different levels, and the operation interface can be logged out to avoid human error.
2. Quality Function
① Control method: Balanced Temperature and Humidity Control (BTHC) high-precision temperature and humidity control system, with multi-stage program settings and multi-point calibration functions;
② Heating control method: high-precision temperature sensor, independent over temperature protection, reasonable air duct structure, forced convection circulation;
③ Refrigeration control mode: automatic switching of dual refrigeration cycle system, a new refrigerant that meets international environmental requirements;
④ Humidity control method: high-precision humidity sensor, automatic circulating water supply system;
⑤ ★Illumination adjustment: high-precision illumination sensor, automatic monitoring and adjustment of illumination inside the box;
⑥ Safety features: independent temperature limit protection for the studio, water cut-off protection for the humidification system, overload protection for the refrigeration unit, and temperature and humidity upper and lower limit deviation alarm system;
⑦ Can be used for long-term, intermediate, and accelerated testing in relevant standards such as the National Pharmacopoeia, GMP, FDA, and ICH, as well as for drug requirements for environmental conditions such as temperature, humidity, and light.
3. Humanized design structure
① ★7.0-inch true color touch screen display, multiple sets of data are displayed on one screen, real-time data curves and fault information are quickly queried, and the operation interface supports switching between Chinese and English;
② The inner liner is made of high-quality 304 stainless steel and features a full arc design for easy cleaning and maintenance;
③ ★Unique air duct design, standard 20mm inner diameter test hole, convenient for operators to expand the functionality of the test chamber;
④ Standard UV disinfection control system.
Product parameters
Note:
1. The relevant data were measured at an ambient temperature of 25 ℃ and a relative humidity of no more than 85%.
2. The experiment shall be conducted after the equipment has been running stably for 2 hours.
